Soosan SB50 Hammer Rock Breaker 100mm Chisel , Yantai Hydraulic Hammer Side Type

Soosan SB50 Hammer Rock Breaker 100mm Chisel , Yantai Hydraulic Hammer Side Type
Soosan SB50 Hammer Rock Breaker 100mm Chisel , Yantai Hydraulic Hammer Side Type Soosan SB50 Hammer Rock Breaker 100mm Chisel , Yantai Hydraulic Hammer Side Type

Large Image :  Soosan SB50 Hammer Rock Breaker 100mm Chisel , Yantai Hydraulic Hammer Side Type

Product Details:
Place of Origin: YANTAI,CHINA
Brand Name: JISAN
Certification: CE, ISO
Model Number: JSB900
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation ( EXW , FOB or CIF price )
Packaging Details: Export Wooden Cases or pallets
Delivery Time: 5-7 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 Sets per year
Detailed Product Description
Working Pressure: 150-170 Kg/cm2 Chisel Diameter: 100 Mm
Impact Rate: 400-700 Bpm Weight: 950 Kg
Hose Diameter: 3/4 Inch Warranty: 14 Months
High Light:

hydraulic hammer breaker

,

rock breaking hammer



Soosan SB50 Hammer Rock Breaker Hydraulic Demolition Equipments For Excavator





Our breaker includes side type, top type, silenced type and backhoe loader type breaker.





Description



1. Real manufacturer, we make all the components with our own technology
2. Easy fitment onto any kinds of excavators
3. Durable body incorporating heavy duty rock claws
4. Perfectly matched tool and piston ensure maximum energy transfer to the material being broken
5. The hydraulic accumulator gives greater acceleration in the power stroke and reduces pressure peaks in the carrier hydraulic system.

6. Powerful hammering and long working life

7. Hydraulic breakers are widely applied to rock broken, mining, road, building engineering, dismantling engineering and special engineering (underwater project, tunnel project), etc.



Soosan SB50 Hammer Rock Breaker 100mm Chisel , Yantai Hydraulic Hammer Side Type 0





Specification



Model Weight (Kg) Length (Mm) Pressure (kg/cm2) Flux (L/Min) Rate (Bpm) Hose (Inch) Chisel (Mm) Suit (Ton)
JSB200 100/120 1100 90-120 15-25 700-1200 1/2 45/53 1.2-3.0
JSB400 298 1347 110-140 25-45 500-900 1/2 68/70 3.0-5.5
JSB600 421 1528 110-160 30-45 500-800 1/2 75 4.0-7.0
JSB800 577 1920 120-170 45-85 400-700 3/4 85 7.0-14
JSB900 973 2260 150-170 80-120 400-700 3/4 100 11-16
JSB1600 1855 2695 160-180 120-160 400-700 1 135 19-26
JSB1900 1989 2810 160-180 130-170 400-600 1 140 19-26
JSB2800 2420 2895 160-180 150-190 350-500 1 150 27-38
JSB3500 2750 3152 160-180 170-220 250-400 1 155 28-40
JSB4500 3160 3310 160-180 200-300 250-350 1.25 165 36-45
JSB5000 4210 3400 160-180 210-290 200-350 1.25 175 40-55
JSB5500 4720 3400 180-220 220-300 200-250 1.25 185 50-60
JSB6000 4910 3420 180-220 230-320 180-200 1.25 190 55-65
JSB6500 6100 3700 190-230 360-450 120-200 1.25 210 65-100



Soosan SB50 Hammer Rock Breaker 100mm Chisel , Yantai Hydraulic Hammer Side Type 1





Application



1. Mining: Mountains, mining, crushing, secondary crushing
2. Metallurgy, slag cleaning, ladle furnace demolition, demolition equipment foundation body dissatisfied
3. Railway, tunnel, bridge, mountain down.
4. Highway: highway repair, cement pavement broken, foundation excavation.
5. Municipal gardens, concrete crushing, gas engineering construction, the transformation of the old city.
6. Building: the old building demolition, reinforced concrete broken.





Company Introduction



Jisan Heavy Industry Ltd. is a leading manufacturer of hydraulic breaker and attachments, widely used in the construction, demolition, mining industries and special project. At present, the capacities of research and development, and manufacturing and the level of quality control stand at the forefront of the industry regarding comprehensive strength.



After nearly ten years of development, we process a professional and experienced technical research team, We have over 300 employees, includes over 40 engineers, production workshop cover 30,000 square meters. With advanced testing equipments, leading R&D capability, and LPS production line, the company has passed authentication of BV, SGS, and CE certification. Quality is the life of enterprise! Grasp the quality source in all the details.
