Product Details:
Payment & Shipping Terms:
|
Working Pressure: | 110-140 Kg/cm2 | Length: | 1347mm |
---|---|---|---|
Required Oil Flow: | 40-70 L/Min | Application: | Demolition , Quarry , Mining Etc |
Weight: | 290 Kg | Service: | OEM Service Available |
Highlight: | excavator hydraulic breaker,excavator concrete breaker,290 Kg Excavator Hydraulic Breaker |
Okada Excavator Hammer Rock Breaker Attachment 290 Kg Hydraulic Breaker Mini Excavator Jack Hammer For Hyundai R55 R60
jisan hydraulic breaker 2022.pdf
JISAN hydraulic rock breakers bring powerful performance and high productivity. Whether for demolishing concrete or breaking rocks, JISAN breakers are designed to give you maximum productivity and minimum breakdown. JISAN Breaker is your first choice for economic, reliable performance, long durability and low maintenance cost.
Description
1. High Strength and wear resistance steel plate adopted for main parts.
2. Compatible with various brands of excavator and backhoe loader.
3. Well heat treatment for through bolt and cylinder, protecting hydraulic breaker from fracture damage.
4. Unique valve system. JISAN hydraulic breakers adopt simple hydraulic circuit system, which reduce oil consumption and improve work efficiency.
5. First-class quality. Introduce processing equipments and experienced technician from Korean.
6. Powerful stroke. Compared with other brand, JISAN breaker has more powerful stroke and reliable performance.
Problemsinoperation
Ifthebreakerdonotworkorbelowfrequencyandblowpowergetworse,checkthearranging method.Andtheninspectaccordingtothefollowingorder.
Gasleakage
Oilleakage
Evenifoilisleaking,itisnecessarytoreplacepartsatalltimes.Checkthefollowingpointslisted inthechartbelow.Theusercancheckthemarkedpointsbeforecallingthedealer.
Specification
Model | Weight (Kg) | Length (Mm) | Pressure (kg/cm2) | Flux (L/Min) | Rate (Bpm) | Hose (Inch) | Chisel (Mm) | Suit (Ton) |
JSB200 | 100/120 | 1100 | 90-120 | 15-25 | 700-1200 | 1/2 | 45/53 | 1.2-3.0 |
JSB400 | 298 | 1347 | 110-140 | 25-45 | 500-900 | 1/2 | 68/70 | 3.0-5.5 |
JSB600 | 421 | 1528 | 110-160 | 30-45 | 500-800 | 1/2 | 75 | 4.0-7.0 |
JSB800 | 577 | 1920 | 120-170 | 45-85 | 400-700 | 3/4 | 85 | 7.0-14 |
JSB900 | 973 | 2260 | 150-170 | 80-120 | 400-700 | 3/4 | 100 | 11-16 |
JSB1600 | 1855 | 2695 | 160-180 | 120-160 | 400-700 | 1 | 135 | 19-26 |
JSB1900 | 1989 | 2810 | 160-180 | 130-170 | 400-600 | 1 | 140 | 19-26 |
JSB2800 | 2420 | 2895 | 160-180 | 150-190 | 350-500 | 1 | 150 | 27-38 |
JSB3500 | 2750 | 3152 | 160-180 | 170-220 | 250-400 | 1 | 155 | 28-40 |
JSB4500 | 3160 | 3310 | 160-180 | 200-300 | 250-350 | 1.25 | 165 | 36-45 |
JSB5000 | 4210 | 3400 | 160-180 | 210-290 | 200-350 | 1.25 | 175 | 40-55 |
JSB5500 | 4720 | 3400 | 180-220 | 220-300 | 200-250 | 1.25 | 185 | 50-60 |
JSB6000 | 4910 | 3420 | 180-220 | 230-320 | 180-200 | 1.25 | 190 | 55-65 |
JSB6500 | 6100 | 3700 | 190-230 | 360-450 | 120-200 | 1.25 | 210 | 65-100 |
Application
1. Mining: Mountains, mining, crushing, secondary crushing
2. Metallurgy, slag cleaning, ladle furnace demolition, demolition equipment foundation body dissatisfied
3. Railway, tunnel, bridge, mountain down.
4. Highway: highway repair, cement pavement broken, foundation excavation.
5. Municipal gardens, concrete crushing, gas engineering construction, the transformation of the old city.
6. Building: the old building demolition, reinforced concrete broken.
Company Introduction
JISAN Heavy Industry Ltd has been exporting the JISAN series hydraulic breaker and other excavator attachments all over the world for nearly ten years.
JISAN always pursues customer satisfaction and technical innovation for excavator attachments. Customer First and Always Honesty are our promise and core value.
Through continuous investment and R&D, JISAN has grown to the leading manufacturer in the industry.
Quality is the life of enterprise. Reliability on products comes from exhaustive inspection and through such analysis as mechanical and physical properties over the whole processes.
