CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade

Certification
China JISAN HEAVY INDUSTRY LTD certification
China JISAN HEAVY INDUSTRY LTD certification
I'm Online Chat Now

CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade

CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade
CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade

Large Image :  CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade

Product Details:
Place of Origin: China
Brand Name: JISAN
Certification: CE, ISO
Model Number: JSD280F
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation ( EXW , FOB or CIF price )
Packaging Details: Export Wooden Cases or Pallets
Delivery Time: 7-15 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 Sets per Month
Detailed Product Description
Color: As Request Weight: 2800kg
Crushing Force: 70 Metric Ton Application: Multi Use, Demolition, Scrap Handling Etc
Working Pressure: 300 Bar Speed Up Valve: Yes
Warranty: 1 Year Condition: New
After-sales Service Provided: Video Technical Support,Online Support
High Light:

CAT230 Excavator Metal Shears

,

Excavator Demolition Shear With Replaceable Blade

,

Demolition Hydraulic Metal Shears

CAT230 Excavator Metal Shears , Scrap Shear Attachment Hydraulic Cutting Machine

Parameter



Item/Model Unit JSD40F JSD50F JSD80F JSD180F JSD280F JSD380F JSD480F
Suitable Excavator T 3-4 4-5 6-8 12-18 20-30 a:33+/b:24+ b:40+
Weight kg 330 450 800 1540 2800 a:4300/b:4800 b:6200
Opening mm 225 375 505 680 740 800 920
Cutting Depth mm 180 280 400 500 550 650 750
Length mm 1120 1310 1570 1950 2207 a:3200/b 180
Blade Length mm 165+103 205+155 260+175 325+210 350+260 350+360 400+400
Cutting Force metric ton 37 50 62 106 156 250 350
Working Pressure bar 24 24 27 300 320 320 350
Cycle Time Open sec 1.8 2.0 2.1 2.4 2.5 2.8 3.0
Close sec 3.6 3.8 3.8 4.1 4.3 4.5 4.8


CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade 0



Features


1. Excavator hydraulic shears are the most versatile tools for demolition and recycling operations.
2. Hydraulic study Rotation: Full 360° hydraulic rotation motor, apply for any location
3. Speed Valve: Speed Valve reduces cycle time
4. High quality Cylinder: Made of special designed sealing structure, strong power with long durability
5. Jaw and Tooth: Use high strength steel, wide jaw opening
6. Replaceable blade, easy for maintenance
7. Made of high strength abrasion-resistant steel, long durability

8. Really simple head adjustment device maximize the operation efficiency

9. JISAN crusher can be suitable for a variety of working environment, not only outstanding performance in handling broken-dismantled work, but also in recycling of concrete material.


 CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade 1


Packing & Delivery

Package
Inner is stretch film, outside is export wooden case or as customer’s request
Delivery
1. Delivery time: Usually 5-7days (1-5sets) after down payment.
2. We can arrange ocean or air transportation according to your request from any port of China.
3.The standard free spare parts: one equipment, one hoses, one set of repair tools with tool box, one certificate and one brochure.
CAT230 Excavator Metal Shears Scrap Shear Attachment With Replaceable Blade 2
Company Introduction

Jisan Heavy Industry Ltd. is a leading manufacturer of hydraulic breaker and attachments, widely used in the construction, demolition, mining industries and special project. At present, the capacities of research and development, and manufacturing and the level of quality control stand at the forefront of the industry regarding comprehensive strength.

After nearly ten years of development, we process a professional and experienced technical research team, We have over 300 employees, includes over 40 engineers, production workshop cover 30,000 square meters. With advanced testing equipments, leading R&D capability, and LPS production line, the company has passed authentication of BV, SGS, and CE certification. Quality is the life of enterprise! Grasp the quality source in all the details.
