Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models

Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models
Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models

Large Image :  Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models

Product Details:
Place of Origin: CHINA
Brand Name: JISAN
Certification: CE,ISO
Model Number: JSP450
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation ( EXW , FOB or CIF price )
Packaging Details: Export Wooden Cases or pallets
Delivery Time: 5-7 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 Sets per year
Detailed Product Description
Rotating Degree: 180/360 Degree Motor: Rotating Motor
Composition: Assistant Hand,main Body, Clip Mouth Suitable Excavator: 40-65 Ton
Color: Green Or As Request Power: Hydraulic Power
High Light:

Building Foundation Hydraulic Pile Hammer

,

Excavator Hydraulic Pile Driving Hammer

,

Hydraulic Pile Hammer 360 Degree

Excavator Pile Hammer Attachments Vibratory Hammer Sheet Piling Driver


Features

Hydraulic pile driver is using its high frequency vibration to vibrate pile body with high acceleration to pass the vertical vibration of mechanical produce to pile which leading to changes in the soil structure around the pile, strength decrease. Soil around the piles become liquefaction to reduce frictional resistance between side of the pile and the soil. Then using the excavator down force, vibrating pile hammer and pile body weight to sink pile into the soil. When extracting piles, in the condition of vibration to pull out the pile by using excavator lift force. Excitation force needed by pile driving machinery are comprehensive determined by site soil, soil condition, moisture content and type of pile, construction.



Advantage of Brand Excavator Sheet Pile Hammer

1. High efficiency of driving piles
2. Easy operation and maintenance
3. Environment-friendly product
4. High quality components
5. Long lifespan



Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models 0

Parameter



ItemModel Unit JSP180 JSP250 JSP280 JSP330 JSP350 JSP450
Eccentric Moment Nm 32 36 40 50 65 85
Frequency rpm 2500 2800 2800 2800 2800 2800
Centrifugal Force KN 271 265 330 420 580 750
Working Pressure bar 300 300 320 320 320 320
Oil Flow L/min 120 155 155 168 210 255
Max Turning degree 180 180 180/360 180/360 180/360 180/360
Weight Main Body kg 1100 1700 1900 2600 2800 2960
Extension Boom kg 260 500 500 700 700 740
Total weight kg 1360 2200 2400 3300 3500 3700
Applicable Excavator Ton 12-17 18-25 25-30 30-40 40-50 40-65


Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models 1

Application

hydraulic vibratory pile driver is using vibrating pile sinking to drive or extract piles. It is especially suitable for municipal, bridges,cofferdam,building foundation etc.

Customization Available Hydraulic Pile Hammer Pile Driver Extractor In All Models 2

Company Introduction

Jisan Heavy Industry Ltd. is a leading manufacturer of hydraulic breaker and attachments, widely used in the construction, demolition, mining industries and special project. At present, the capacities of research and development, and manufacturing and the level of quality control stand at the forefront of the industry regarding comprehensive strength.

After nearly ten years of development, we process a professional and experienced technical research team, We have over 300 employees, includes over 40 engineers, production workshop cover 30,000 square meters. With advanced testing equipments, leading R&D capability, and LPS production line, the company has passed authentication of BV, SGS, and CE certification. Quality is the life of enterprise! Grasp the quality source in all the details.
