Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service

Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service
Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service

Large Image :  Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service

Product Details:
Place of Origin: China
Brand Name: Jisan
Certification: CE, ISO
Model Number: JS380RT
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation ( EXW , FOB or CIF price )
Packaging Details: Export Wooden Cases or pallets
Delivery Time: 10-14 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 Sets Per Year
Detailed Product Description
Weight: 3500kg Height: 2830 Mm
Cycle Time (Open): 2.4 Seconds Material: Q345B, HARDOX 500/600
Application: Thick Steel, Scrap Ship Cutting Etc Warranty: 14 Months
High Light:

Scrap Scissors Excavator Metal Shears

,

OEM Excavator Metal Shears

,

Q345B Hydraulic Metal Shear

Customized Multi-Functional Hydraulic Scrap Scissors For Excavators New Product 2022 OEM Service Provided Hydraulic



Product Description



Hydraulic steel cutting shear can be used in all industrial demolition sites for the cutting and recovery of scrap materials such as iron sections, pipes, tanks, railway carriages etc.





jisan hydraulic power shear



Mobile scrap shears to process ferrous metals, aluminium and other non-ferrous metals have manufactured highly-efficient demolition shears to effectively cut ferrous and non-ferrous materials. mobile scrap shears efficiently reduce the size of steel and aluminium bars, profiles and downsize bulky scrap.

Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 1 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 2 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 3 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 4

mobile scrap shears are ideal for processing:
Ferrous bars, rods and I-beams
Bulky, bulky and oversized scrap metal
Aluminium scrap, bars and profiles
End-of-life ships and aircraft
Railway and tramway lines



Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 5 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 6 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 7 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 8


The demolition shears for unrivalled results
The exceptional cutting force of demolition attachments are due to the combined effect of high performance cutting blades, reliable gearboxes and a robust torsion free main body made from the finest steel. Depending on the material you need to process, has the right sized shear to suet your excavator. manufacture a series of demolition shears specifically suited to the job requirements. With 8 different models of mobile scrap shears to choose from, you can be sure that have the right shear in the correct size and weight in order to satisfy even the most specific production requirements.



Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 9 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 10 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 11 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 12


Extremely powerful cutting performance
The wide jaw opening of demolition shears guarantees high cutting performance while a large discharge area on the non-cutting side of the mobile jaw ensures quick discharge rates without blocking. mobile scrap shears are also equipped with a sturdy large-bore hydraulic main cylinder and a central pin designed to be especially resistant to thrust damage. The extremely high durability of the central pin is due to a specific production procedure known as ‘cryogenic shrink fitting’ where the pin is cooled down using liquid nitrogen before inserting in to the housing. The gradual warming back to room temperature creates a perfect fit in the pin housing for better durability and reliability.



Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 13 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 14 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 15 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 16


Mobile rail shears and rail cutting accessories
The series of shears and rail cutting attachments are specifically designed to quickly and efficiently cut all kinds of rail. Due to the high rebound shock involved in cutting train track rails, the shear needs to be built extra robustly. years of experience coupled with feedback from many international customers have led to design and build the perfect shear to reliably cut rail road tracks and tram rails down to a manageable size.



Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 17 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 18 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 19 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 20


manufacture a full range of demolition shears:
mobile scrap shears
Demolition shears for ferrous metals, aluminium, non-ferrous metals
mobile shears
Hydraulic breakers and attachments for cutting rails



Features



1. JISAN POWER SHEAR is OEM supplier of SANY GROUP, CATERPILLAR CHINA. KOMATSU CHINA.

2. Material : HARDOX 500

3. BLADES MADE IN GERMANY.

4. ROTATION MOTOR MADE IN FINLAND.

5. 360 degree hydraulic rotation, increase working efficiency
6. Speed Valve installed, reduces cycle time
7. Easy to replace the blade, reduces machine downtime
8. Made from wear resistant steel to ensure maximum strength
9. Use for cutting iron material, steel structure, pipes etc

10. Increased cylinder size for 30% more power. Forged cylinder rod for better functionality and security.

11. Short opeing and closing cycle time

12. Applied to handle H-beam, I-beam steel, ,automobile beam, workshop girder, especially suitable for heavy duty steel cutting, which can reach maximum efficiency.

13. Up to 1500T cutting force, more powerful shear work.

14. Jaw size and special blade design to improve productivity. The full range of eagle nose pliers allows quick and easy blade replacement, which reduces downtime and optimizes productivity.

15. Powerful hydraulic cylinder greatly strengthens the jaw mouth closing force to cut the hard steel

16. Eagle nose pliers series products are made of high grade steel, to ensure greater strength and better wear resistance of tools.

17. Corrosion resistance and waterproof design

18. Fully enclosed, steel plate construction designed to eliminate and reduce twisting or bending on any side



Parameter



Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 21



Item/Model Unit JS180RT JS280RT JS350RT JS380RT JS450RT JS500RT JS580RT JS780RT JS980RT
Arm Installation Ton 13-17 18-27 25-35 28-39 40-50 42-50 51-65 68-90 91-110
Boom Installation ton 10-12 14-18 20-28 20-28 28-39 28-39 40-50 51-65 66-90
Weight Kg 1100 2800 4000 4500 5500 6000 7000 7800 9800
Opening A mm 375 485 595 600 700 800 850 900 1000
Cutting Depth B mm 395 525 630 680 720 800 800 850 940
Length C mm 2100 2700 3200 3280 3700 3800 4000 4300 4600
Driving Pressure Kg/cm2 250-300 250-300 300-320 320-350 320-350 320-350 320-350 320-350 320-350
Driving Flow Lpm 90-110 180-220 200-250 200-250 250-300 250-300 275-375 500-600 600-700



Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 22 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 23 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 24 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 25 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 26 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 27
High strength motor Speed valve Maintenance port Discharge port Central pin Rotating device
Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 28 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 29 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 30 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 31 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 32 Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 33
Pin Blade made in germany Wear-resistant jaw Stable device Blade with bolt Ball joint



Our Service



It is equipped with high-strength and large-capacity oil cylinder inverted installation, which realize the large shearing force. The use of honing process wear-resistant thick cylinder barrel to ensure long service life. Jisan provides cylinder maintenance and upgrading services. Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 34
Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 35 Jisan provides services to support the reuses of blade for hydraulic shear. The blade is reused and can be turned over regularly, which not only improves the life of the blade to reduce the cost, but also improve the efficiency of dismantle.
Jisan can provide customized processing services for customer. Hardox steel is finely cut using high-precision CNC machine tools to ensure that each component can be accurately connected to achieve high efficiency and durability. Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 36
Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 37 Jisan supports special design and installattitude of high quality requirementsation services. All components are welded by senior engineers with many years of precise welding technology, so as to ensure the fatigue resistance and crack resistance of high-strength operations.
Supporting special high-pressure wear-resistant pipelines with universal design,allows it can be adapted to various excavator models, breakers,attachments and other equipment. Jisan provides high-quality full ranges of pipelines and installation services. Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 38



jisan hydraulic power shear



Multi Functional Hydraulic Scrap Scissors Excavator Metal Shears OEM Service 40





Our Service



1. 12 months after-sales warranty for hydraulic motor and cylinder.
2. Our professional team (pre-sales service, technical team,after-sales service) will solve all your problems.
3. Every Product will do impact test before delivery to our customer.
4. Your inquiry will be replied in eight hours
5. OEM and ODM Service available



Company Introduction



Jisan Heavy Industry Ltd. is a leading manufacturer of hydraulic breaker and attachments, widely used in the construction, demolition, mining industries and special project. At present, the capacities of research and development, and manufacturing and the level of quality control stand at the forefront of the industry regarding comprehensive strength.

After nearly ten years of development, we process a professional and experienced technical research team, We have over 300 employees, includes over 40 engineers, production workshop cover 30,000 square meters. With advanced testing equipments, leading R&D capability, and LPS production line, the company has passed authentication of BV, SGS, and CE certification. Quality is the life of enterprise! Grasp the quality source in all the details.



Our products have been exported to many countries in the world including India, Saudi Arabia, South America, Australia,
New Zealand, Southeast Asia, USA, Europe, and South Africa etc.



Mobile scrap shears to process ferrous metals, aluminium and other non-ferrous metals have manufactured highly-efficient demolition shears to effectively cut ferrous and non-ferrous materials. mobile scrap shears efficiently reduce the size of steel and aluminium bars, profiles and downsize bulky scrap.



mobile scrap shears are ideal for processing:
Ferrous bars, rods and I-beams
Bulky, bulky and oversized scrap metal
Aluminium scrap, bars and profiles
End-of-life ships and aircraft
Railway and tramway lines



The demolition shears for unrivalled results
The exceptional cutting force of demolition attachments are due to the combined effect of high performance cutting blades, reliable gearboxes and a robust torsion free main body made from the finest steel. Depending on the material you need to process, has the right sized shear to suet your excavator. manufacture a series of demolition shears specifically suited to the job requirements. With 8 different models of mobile scrap shears to choose from, you can be sure that have the right shear in the correct size and weight in order to satisfy even the most specific production requirements.



Extremely powerful cutting performance
The wide jaw opening of demolition shears guarantees high cutting performance while a large discharge area on the non-cutting side of the mobile jaw ensures quick discharge rates without blocking. mobile scrap shears are also equipped with a sturdy large-bore hydraulic main cylinder and a central pin designed to be especially resistant to thrust damage. The extremely high durability of the central pin is due to a specific production procedure known as ‘cryogenic shrink fitting’ where the pin is cooled down using liquid nitrogen before inserting in to the housing. The gradual warming back to room temperature creates a perfect fit in the pin housing for better durability and reliability.



Mobile rail shears and rail cutting accessories
The series of shears and rail cutting attachments are specifically designed to quickly and efficiently cut all kinds of rail. Due to the high rebound shock involved in cutting train track rails, the shear needs to be built extra robustly. years of experience coupled with feedback from many international customers have led to design and build the perfect shear to reliably cut rail road tracks and tram rails down to a manageable size.



manufacture a full range of demolition shears:
mobile scrap shears
Demolition shears for ferrous metals, aluminium, non-ferrous metals
mobile shears
Hydraulic breakers and attachments for cutting rails
