Product Details:
Payment & Shipping Terms:
|
| Power Of Impulse: | 5 Ton | Number Of Damper: | Four Imported Damper |
|---|---|---|---|
| Weight: | 300 Kg | Applicable Excavator Brand: | Doosan,Daewoo,Volvo,Hitachi,Kato,Kabelco,Komatsu,Sumitomo,Cat Etc. |
| Dimension(L*W*H): | 900*550*760 Mm | Advantage: | High Efficiency, Long Workiing Life |
| High Light: | Honda Attachment Excavator Compactor Plate,Jack Hammer Excavator Compactor Plate,Diesel Hydraulic Plate Compactor |
||
Excavator Compactor Plate Jack Hammer Quality Sale Oem Odm Service Ce New Product Machine Diesel Honda Attachment
jisan hydraulic plate compactor 2022.pdf
Advantages
It is used in municipal construction projects— Abutment back, culvert side, corner turn,Road and railway subgrade, such as shoulder and slope protection tamping, embankment and its slope tamping, Building trench and fill earth compacted, concrete road repair, municipal side ditch, well and tube side, etc.
1. Using special steel material with high ductility and high abrasion resistance.
2. Using famous imported brand hydraulic vibration motor, sturdy and durable.
3. Reasonable mechanics structure, strong and durable.
4. Using Sweden imported cylindrical roller bearing with low noise, high speed and reliable.
5. Using high strength plate and high wear-resisting board(Hardox) in key parts to guarantee quality.
Technical Parameter
| Item/Model | Unit | JSC02 | JSC03 | JSC06 | JSC08 | JSC10 |
| Carrier | Ton | 1-3 | 4-9 | 11-16 | 17-23 | 23-30 |
| Power of Impulse | Ton | 3 | 5 | 10 | 15 | 15 |
| Maximum vibration frequency | Rpm | 2000 | 2000 | 2000 | 2000 | 2000 |
| Oil Flow | L/min | 30-45 | 45-75 | 85-105 | 120-170 | 120-170 |
| Pressure | Kg/cm2 | 100-120 | 100-130 | 100-130 | 150-200 | 150-200 |
| Weight | Kg | 260 | 300 | 500 | 900 | 950 |
| Bottom Measurement | L*W*T,mm | 650*470*16 | 900*550*25 | 1160*700*28 | 1350*900*30 | 1350*900*30 |
| Height | Mm | 690 | 760 | 920 | 1060 | 1100 |
| Width | Mm | 470 | 550 | 700 | 900 | 900 |
Application
Applied to any position, such as horizon compaction, step compaction, bridge abutment , the trench pit compaction, sub grade compaction, the corner turning point, backfill compacted, concrete pavement patching compacted, tube side compaction etc.
1.JISAN series hydraulic compactor can be applicable to any position, such as horizon compaction, step compaction, brige abutment, the trench pit compaction, subgrade compaction,the corner turning point, backfill compacted, concrete pavement patching compacted, tube side compaction etc.
Product Inspection
1. Every Product will pass through ring upon ring of quality inspection before delivery to our customer.
2. We will do impact test for every product before delivery.
Why choose us
1. Rich experience in excavator attachments and other parts.
2. We not only sell the products, but also can design as customer's request.
3. We can design and produce a wide range of excavator attachments.
4. Quality is guaranteed by skilled workers, honest employee and QC team.
5. Excellent quality, competitive price & professional service.
