F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker

F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker

Large Image :  F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker

Product Details:
Place of Origin: Shandong, China
Brand Name: JISAN
Model Number: JSB
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $2,900-3,800
Contact Now
Detailed Product Description
Weight: 264 Kg Length: 1528 Mm
Rod Diameter: 68mm Suitable Excavator: 4-7 Ton
Operating Pressure: 90-120 Bar Flow Rate: 15-25 Lpm
Impact Rate: 900-1400 Bmp Hose Size: 1/2 Inch
Chisel Diameter: 40 Mm Core Components: Engine
Type: Side Type Color: Yellow
Material: Korea Made Cylinder Oil Seal: NOK Oil Seal
Noise Level: Low Noisy
Highlight:

F22 hydraulic concrete breaker

,

F27 hydraulic rock breaker

,

hydraulic breaker with warranty

F22/F27 Hydraulic Breaker Specifications
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 0 F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 1
Technical Parameters
Item/Model Weight (kg) Length (mm) Pressure (bar) Flow (lpm) Rate (bmp) Hose (inch) Chisel (mm) Suit (ton)
JSB100100100090-12015-25900-14001/2400.8-2.0
JSB200167130090-12020-40700-12001/2451.2-3.0
JSB300194140090-12025-50600-11001/2532.5-4.5
JSB4003631700110-14040-70500-9001/268/704-7
JSB6004501750110-16050-90500-8001/2756-9
JSB8007302100120-17060-100400-7003/4857-14
JSB9009702400150-17080-120400-7003/410011-16
JSB160019502700160-180120-160400-700113519-26
JSB190020502860160-180130-170400-600114019-26
JSB350030003100160-180170-220250-400115528-40
JSB450033003286160-180200-300250-3501 ¼16536-45
JSB500042503800160-180210-290200-3501 ¼17540-55
JSB500049003700180-220220-300200-2501 ¼18550-60
JSB600054004200200-240230-320150-2001 ¼19555-65
JSB650074004300200-240320-490150-2001 ¼20565-100
Product Features
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 2
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 3

The excavator hydraulic breaker is a versatile front-end equipment accessory with high strength, compact size, and powerful performance. Designed for efficient concrete breaking, mining operations, boulder demolition, and emergency rescue situations, these breakers are essential tools for construction, demolition, and disaster relief applications.

Key Applications:
  • Construction demolition operations
  • Reinforced concrete separation
  • Primary rock excavation
  • Secondary rock breaking
  • Trenching and foundation work
  • Asphalt cutting
  • Emergency rescue operations
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 4 F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 5
Safety Operation Guidelines
1. Proper Positioning: Ensure correct breaker position for effective force application. Incorrect positioning reduces impact efficiency.
2. Avoid Excessive Force: Prevent machine tipping by avoiding excessive downward pressure when breaking.
3. Vibration Control: Minimize vibration transmission to machine tracks during operation.
4. Correct Tool Alignment: Maintain vertical chisel position to prevent tool damage.
5. Proper Usage: Never use the breaker for rock moving or debris sweeping.
6. Water Protection: Avoid submersion of breaker components in water or mud.
7. Warm-up Procedure: Allow proper warm-up time, especially in cold conditions (5-10 minutes at 30-40°C).
8. Avoid Blank Hammering: Prevent excessive wear by avoiding operation without contact surface.
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 6
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 7
Company Advantages
  • 12 years experience as leading hydraulic breaker manufacturer
  • Global exports to India, Saudi Arabia, South America, Australia, and more
  • Premium components: Korea-made cylinders, NOK oil seals
  • Low-noise operation with full-closed housing protection
  • High-impact performance with extended service life
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 8
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 9
Product Packaging
  • Inner stretch film with export wooden case packaging
  • Standard accessories: Two chisels, two hoses, repair tool set, nitrogen bottle
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 10
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 11
How to choose the right breaker model
Certifications & Recognition

JISAN has earned global recognition through international exhibitions and holds various patent certificates for our hydraulic breaker technology.

F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 12
F22 Hydraulic Breaker, Hydraulic Concrete Breaker, F27 Hydraulic Breaker 13
