Stone Excavator Grapple Bucket Fixed Type Hydraulic Power High Strength Steel Grab

Certification
China JISAN HEAVY INDUSTRY LTD certification
China JISAN HEAVY INDUSTRY LTD certification
I'm Online Chat Now

Stone Excavator Grapple Bucket Fixed Type Hydraulic Power High Strength Steel Grab

Stone Excavator Grapple Bucket Fixed Type Hydraulic Power High Strength Steel Grab
Stone Excavator Grapple Bucket Fixed Type Hydraulic Power High Strength Steel Grab Stone Excavator Grapple Bucket Fixed Type Hydraulic Power High Strength Steel Grab

Large Image :  Stone Excavator Grapple Bucket Fixed Type Hydraulic Power High Strength Steel Grab

Product Details:
Place of Origin: China
Brand Name: JISAN
Certification: CE, ISO
Model Number: JSS08
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation ( EXW , FOB or CIF price )
Packaging Details: Export Wooden Cases or pallets
Delivery Time: 5-7 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 Sets per year
Detailed Product Description
Material: Q345B, NM400 Warranty: 14 Months
Type: Rotating Type Or Non-rotating Type Service: OEM Service Available
Suitable Excavator: 17-23ton Excavator Certification: CE, ISO
Cylinder: Cylinder Equipped Power: Hydraulic Power
High Light:

hydraulic grab bucket

,

clamp bucket



Hydraulic Stone Mini Excavator Grab Bucket Rock Grab Excavator Thumb Bucket



Description



The Grab Bucket is essentially a digging bucket with a fitted hydraulic thumb capable of running at full system pressure which allows for a very strong grip.



The powerful cylinder fitted to these heavy-duty buckets provides greater clamping force which allows the operator to work easily with very large items.



Strategically positioned ears on both sides of the cylinder protect it from any damage.



Stone Excavator Grapple Bucket Fixed Type Hydraulic Power High Strength Steel Grab 0



Parameter



Item/Model Unit JSS02 JSS03 JSS04 JSS06 JSS08 JSS10
Weight Kg 180 360 520 840 1430 1860
Max Jaw Opening mm 818 1150 1380 1550 2220 2235
Oil Pressure kg/cm² 100-130 110-140 120-160 150-170 160-180 160-180
Set Up Pressure kg/cm² 150 170 180 190 200 210
Operating Flux L/min 25-40 30-55 50-100 90-110 100-140 130-170
Cylinder Volume Ton 4.0 5.4 5.4 8.2 10.0 12.0
Suitable Excavator Ton 2-3 4-6 7-11 12-16 17-23 24-30



Stone Excavator Grapple Bucket Fixed Type Hydraulic Power High Strength Steel Grab 1



Working Scene



Grab bucket we manufactured can fit for all the world famous excavator brands,such as Komatsu, Kobelco, Hitachi, Sany, Volvo, Case, Hyundai etc.



From handling waste, brush and logs to moving stones, pipes and landscaping materials, the clamp bucket is suited to a wide variety of applications.



Stone Excavator Grapple Bucket Fixed Type Hydraulic Power High Strength Steel Grab 2





Packing & Shipping

Package: Inner is stretch film, outside is export wooden case

Production Time: 3-5 Workdays after down payment

Delivery: We can arrange ocean or air transportation according to your request from any port of China.

Shipping term: EXW,FOB, CNF, CIF, DDU, DDP


Shipping port: Qingdao,Tianjin, Shanghai, Ningbo, etc.





Company Introduction


Jisan Heavy Industry Ltd. is a leading manufacturer of hydraulic breaker and attachments, widely used in the construction, demolition, mining industries and special project. At present, the capacities of research and development, and manufacturing and the level of quality control stand at the forefront of the industry regarding comprehensive strength.

After nearly ten years of development, we process a professional and experienced technical research team, We have over 300 employees, includes over 40 engineers, production workshop cover 30,000 square meters. With advanced testing equipments, leading R&D capability, and LPS production line, the company has passed authentication of BV, SGS, and CE certification. Quality is the life of enterprise! Grasp the quality source in all the details.



Stone Excavator Grapple Bucket Fixed Type Hydraulic Power High Strength Steel Grab 3
